As always, it’s all about compression, which is why we’ve created Timbre — an all-tube vari-mu compressor based on the classic 6386 tube, inspired by the iconic and highly sought-after Gates STA-Level compressor. Timbre is simple to use, delivering rich colour and sweetness, designed with the finest components for a truly vintage sound.
To enhance the original design, we’ve introduced new features like a third mode of operation with a faster attack time, a high-pass sidechain filter, stereo linking capabilities, and a bypass function. Timbre also utilises a unique program-controlled release circuit, allowing for smooth and consistent compression while avoiding the typical side effects, even with up to 40dB of gain reduction!
Main Features:
- Famous Gates STA-Level vari-mu compression.
- All-tube balanced circuit featuring the 6386 tube.
- High-quality Carnhill transformers for enhanced sound.
- Single/Double/Triple mode of operation.
- 6-step release time switch for flexible control.
- Switchable sidechain high-pass filter.
- Bypass function for clean signal pass-through.
- Link function for stereo operation.
Specifications:
|
Frequency response |
20Hz-30kHz (0.5dB) |
|
THD+N |
up to 1% |
|
Input impedance |
transformer balanced: 600ohm |
|
Output impedance |
transformer balanced: 600ohm |
|
Max gain |
45dB |
|
Max gain reduction |
40dB |
|
Mode |
single, double, triple |
|
Balanced output and input |
(XLR Amphenol) |
|
Case Rack |
2U |
|
Unit dimensions |
88x483x235 mm |
|
Box dimensions |
274x550x382 mm |
|
Unit weight |
5,6 kgs |
|
Box weight |
7,5 kgs |
|
Warranty |
2 years |
