NG500 fully analog passive equalizer with digital recall
PROMETHEUS is a fully analog passive EQ with +24dBu of headroom, offering a classic Pultec-style warmth enhanced by modern innovations. Its contemporary design enables instant recall of your timeless analog sound through a highly flexible plugin. Like all ng500 products, PROMETHEUS integrates seamlessly with your DAW environment via the front panel USB socket or through the TITAN chassis.
Main Features:
- +24dBu headroom for high dynamic range.
- Operates in Stereo, Dual Mono, and Mid/Side modes for flexible audio applications.
- Passive equalizer design based on Pultec-style inductors.
- Analog inductor for classic tone-shaping.
- Proprietary THD implementation for harmonic distortion control.
- Flexible DAW/Live plug-in control with instant recall functionality.
- 6 touch-sensitive encoders for recording automation.
- True bypass for signal integrity.
- In and Out metering with clip detection for accurate monitoring.
- A/B compare feature for quick preset comparisons.
Stereo/Dual Mono/Mid-Side Operation Modes
PROMETHEUS operates in three distinct modes, including Mid-Side (MS), making it an ideal solution for a wide range of applications and versatile audio processing tasks.
Output Control
Post-EQ output control provides enhanced flexibility, allowing precise adjustments after EQ processing to better shape and balance your audio signal.
Hardware A/B
Even when using PROMETHEUS as a fully analog signal processor, you can effortlessly switch between two parallel settings at the press of a single button, offering seamless flexibility in sound shaping.
THD – Add Colour to Your Mixes
THD, or Total Harmonic Distortion, enhances your signal by introducing subtle analog saturation, adding warmth and richness. This process imparts a pleasing, musical coloration, giving your audio a fuller, more dynamic character.
Flexible DAW/Live Plug-in Control for Instant Recall
- Stereo plugin that manages all modes of operation – Stereo, Dual Mono, and Mid-Side.
- Mono plugin where two separate instances can connect to the same hardware, managing each channel independently.
- IN/OUT metering with clip detection for precise monitoring.
- Plugin available in AAX, AAX DSP, VST3, VST2, and AU formats.
Specifications:
|
Frequency response |
10Hz-150kHz (-2dB) |
|
THD+N < 0.01% |
(1kHz,0dBu) |
|
Input impedance |
10kohm |
|
Output impedance |
< 100ohm |
|
Max signal level |
+24dBu |
|
Crosstalk |
< -100dB |
|
THD (MID switch) |
1% |
|
THD (HIGH switch) |
2.5% |
|
Power consumption |
70mA per rail |
|
Unit dimensions |
76x133x158 mm |
|
Box dimensions |
105x162x234 mm |
|
Unit weight |
0,7 kg |
|
Box weight |
0,9 kg |
|
Warranty |
2 years |
