The Sony C-100 Microphone is a new side-address studio condenser microphone incorporating advanced microphone technology making it compatible with Hi-Resolution Audio. The C-100 has three selectable polar patterns: Omni, Uni (cardioid) and Bi (figure-of-8).
The C-100's newly-developed double microphone capsule uses technology first used on the world famous C-800G studio mic to incorporate advanced noise elimination and amazing reproduction of vocals and musical instruments alike.
With excellent sound quality, a wide frequency response, noise elimination construction, a low cut filter and switchable polar patterns, the Sony C-100 Hi-Res Studio Mic is a powerful recording tool, essential for every studio.
Sony C-100 Hi-Res Mic (Side Address) – Ideal for Vocal Applications
- Supports Hi-Res Recording (～50kHz）in an ultra-compact package
- Two-way structure incorporates newly developed capsules with variable directivity that deliver a wide frequency response of 20Hz to 50kHz
- Selectable pick-up pattern (Omni/Uni/Bi) supports a wide variety of recording applications
- Two-part metallic body structure succeeded from the C-800G microphone prevents acoustic vibration resulting in low noise and clear sound
- Low-Cut filter eliminates low-frequency noise and proximity effect
- -10dB pad switch provides added headroom
Audio Performance
| Capsule Type | 2 Way Microphone (Condenser + Back electret condenser) |
| Frequency Response | 20 Hz to 50 kHz |
| Directivity | Cardioid/Omni directional/Bi directional |
| Sensitivity *[1] | -36 dB |
| Output Impedance *[2] | 90Ω±15%, Balanced |
| Dynamic Range | (Cardioid) 113 dB or more (Omni directional) 114dB or more (Bi directional) 114dB or more |
| Signal-to-Noise Ratio *[3] | (Cardioid) 76 dB or more (Omni directional) 71 dB or more (Bi directional) 73 dB or more |
| Inherent Noise *[4] | (Cardioid) 18 dB SPL or less (Omni directional) 23 dB SPL or less (Bi directional) 21 dB SPL or less |
| Wind Noise *[5] | 50 dB SPL or less (with supplied windscreen)
|
| Maximum Input Sound Pressure Level *[6] | (Cardioid) 131 dB SPL (Omni directional) 137 dB SPL (Bi directional) 135 dB SPL |
Build, W&Ms and What’s Included
| Connector | XLR-3-12C (male) |
| Mic Cable | XLR 3-pin Cable Required (Not Supplied) |
| Power Requirements | +48 V phantom power |
| Dimensions *[7] | 40dia.×175mm (1.57dia.×6.89in.) |
| Mass | Approx. 290g (10.2oz.) |
| Supplied Accessories | Cradle suspention (1) Wind screen (1) Stand screw adaptor (W3/8 to NS5/8) (1) Operating instructions (1) Carrying case (1) |
| Notes | *[1] 0 dB = 1 V/Pa, at 1 kHz *[2] Output impedance at 1 kHz *[3] A-weighted, 1 kHz, 1 Pa. *[4] 0dB SPL = 20μPa. *[5] Wind noise at 2m/s (0 dB SPL = 20μPa.) *[6] 0 dB SPL = 20μPa. *[7] The values for dimensions are approximate |
