Radial Engineering PZ-Pre Acoustic Instrument Preamp

Radial EngineeringSKU: R800 7085 00

Price:
Sale price €499.00

The PZ-Pre is a powerful acoustic instrument preamplifier with a powerful EQ and feedback control section and loads of connectivity options giving you complete control over your rig.

Powerful Control in a Box

The Radial PZ-Pre™ is a powerful acoustic instrument preamplifier. The magic lies in the combination of high performance 100% discrete class-A PZB piezo boosters, an ultra-quiet preamp circuit that will adapt to any pickup system and a host of connectivity options that will put you in total control. The PZ-Pre is equipped with two inputs for quick instrument changes on stage, or, for blending two pickups together. Powerful semi-parametric EQ and feedback eliminating controls allow the user to fine-tune their sound while eliminating troublesome frequencies. Offering both pre and post EQ direct box outputs, the PZ-Pre can be used send a dry signal to the house and performer tailored sound to monitors.

PZ-Pre Applications

Radial PZ-Pre two acoustic flow chart

Using two acoustic guitars on stage

The PZ-Pre is the perfect stage partner for switching between two acoustics. You can have one for backup, alternate tuning or switch from 6-string to 12-string with ease.

Radial PZ-Pre two bass flow chart

Using upright and electric acoustic

Switch between contrabass and electric or acoustic bass with a simple foot stomp! The PZ-Pre's input is easily optimised to work with finicky piezo pickups for a deeper, more natural tone.

Radial PZ-Pre flow chart with violin and mandolin

Using the PZ-Pre on violin and mandolin

Using the PZ-Pre with a piezo transducer will give you more gain before feedback than a microphone. You will be surprised at how good a piezo can sound when connected to a PZ-Pre!

Features:

  • Two channels to switch or blend instruments
  • Notch & resonance filters eliminate feedback
  • Pre & Post Radial DI outputs for PA and monitors
  • Power booster and mute for more control on stage

The Radial PZ-Pre is a high performance preamp designed specifically for acoustic instruments and pickups of all sorts. A proprietary response curve has been developed that works in conjunction with the passive-interactive tone controls and piezo optimized front end to produce a warm yet detailed sonic signature. Exceptionally low noise and distortion differentiate the PZ-Pre from others producing a natural tone that will flatter most instruments of all types.

Specifications

Audio circuit type:

Proprietary active circuit

Number of channels:

Dual Input, Amp Out, Pre and Post EQ XLR balanced Out

Input Impedance:

6.8k Ohm at input jack (PZB active 10meg Ohm)

Output Impedance:

1k Ohm

Features

180° polarity reverse, Ground lift, Effects Loop, EQ Control, Boost

Input Connectors:

1/4"

Output Connectors:

Pre and Post EQ XLR

Extras:

1/4" Effects Loop, Tuner

General

Construction:

14-gauge steel

Size (L x W x D):

8"w x 4 ¼"d x 2"h (205 x 110 x 51mm)

Weight:

2.7lbs (1.2kg)

Power:

15VDC 400mA, center pole positive

Conditions:

For use in dry locations only between 5°C and 40°C

Warranty:

Radial 3-year, transferable
