Radial Engineering ProAV2 Stereo Passive Multimedia Direct Box

Radial EngineeringSKU: R800 1115 00

Price:
Sale price €249.00

The ProAV2 is a stereo passive direct box designed for audio-video integrators and technicians, with an array of input connector options to easily interface with a wide range of audio equipment.

Connect any device to the PA system

The ProAV2 is an indispensable device for live sound engineers and audio-video technicians alike, with the ability to seamlessly interface nearly any device with a pro audio system. A 3.5mm stereo input jack and dual 1/4" and RCA connectors ensure that you won't ever be hunting around for adaptor cables, while ultra-quiet performance with transformer isolation helps eliminate hum and buzz from ground loops. The ProAV2 maintains stereo separation and exhibits linear frequency response from 20Hz to 20kHz, with balanced mic-level XLR outputs that allow you to send signals through a multichannel audio snake on stage or into two channels of a mixing console.

Features:

  • Versatile stereo direct box for multimedia applications
  • Easy to use, ultra-quiet passive design
  • Transformer isolation eliminates hum and buzz
  • Handles huge transients without distortion

ProAV2 Applications

ProAV2: Stereo In ~ Stereo Out

The ProAV2 operates in true stereo (dual mono) making it ideal for stereo devices like laptops and DVD players. Just like the ProAV1 you can connect with phone, RCA and 3.5mm jacks, quick and adapter-free.

Specifications



Audio circuit type:

Passive, transformer based

Transformer:

Eclipse ET-DB2, 12:1 ratio

Number of channels:

Dual channel (stereo)

Frequency response:

20Hz ~ 18.5KHz (± 0.2dB)

Dynamic range:

128dB

Total harmonic distortion:

0.01% from 20Hz~20kHz @-10dB

Phase Deviation:

1° @ 100Hz; 8° @ 20Hz

Input Impedance:

140k Ohms, unbalanced

Output Impedance:

150 Ohms, balanced

Maximum Input:

+18dB @ 20Hz

Features

Ground lift

Input Connectors:

1/4", RCA, 3.5mm TRS

Output Connectors:

XLR

General

Construction:

14-gauge steel chassis & shell

Size (L x W x D):

3.25” x 5” x 1.875”

Weight:

0.82kg / (1.8lbs)

Shipping size (L x W x D):

102 x 76 x 165mm (4.00" x 3.00" x 6.50")

Shipping weight:

1.2 kg (2.60 lbs)

Power:

Passive, no power required

Conditions:

For use in dry locations only between 5°C and 40°C

Warranty:

Radial 3-year, transferable
