Radial Engineering Bassbone V2 Bass Preamp & Boost

Radial EngineeringSKU: R800 7071 00

Price:
Sale price €499.00

The Bassbone V2™ is a two channel bass preamp with a number of customisable features to suit any type of setup or playing style, while providing superb audio quality ideal for a live stage or studio recording.

The ultimate bass control centre

The Bassbone V2 combines high quality audio performance with the ability to take control of your tone and configure each feature to match your ideal setup. Seamlessly switch between upright and electric basses, while tailoring the signal from the upright with a three band EQ, high-pass filter, and a high impedance input for a more natural tone. You can engage your effects pedals with a single footswitch, and assign them to either input individually, or share them across both. A wet/dry control for the effects loop provides the ability to blend the original bass signal in with the output from the pedals, preserving the tone and clarity of your instrument. The Bassbone V2 also features a powerful clean boost that can be activated with a footswitch, or reconfigured as a mute switch for silent tuning on stage.

Bassbone V2 Applications

Bassbone V2 Applications: 2 Basses

Using the Bassbone V2 with two basses

The Bassbone V2 is designed to let you switch between any two basses. Use channel-1 and your amp's EQ to set you primary tone. Use channel-2's ultra powerful EQ to compensate so that each instrument sounds its best.

Bassbone V2 Applications: Eclectric & Piezo Bass

Switching between upright and electric

The Bassbone V2's high performance preamp is well suited for all instruments including upright bass. This lets you toggle between electric and acoustic and optimise the tone going to your stage amp and the PA system. Add effects pedals using the built-in effects loop.

Bassbone V2 Applications: 1 Bass

Using the Bassbone V2 with one bass

The Bassbone V2 is the ultimate front end for any bass. Channel-1 can be set flat or augmented with two modern presets. Channel-2's 3 band EQ is so powerful that it can turn your P-bass into a Rickenbacker!

Features:

  • Two-channel bass preamp for 1 or 2 basses
  • Shared effects loop with footswitch
  • Variable clean boost circuit and EQ controls
  • PZB booster and piezo input for upright bass
  • Built-in Radial DI with balanced output for the PA

Specifications



Audio circuit type:

Discrete class-A FET input with low noise ICs.

Frequency response:

20Hz ~ 18kHz

Dynamic range:

85dB

Gain:

Unity gain device

Total harmonic distortion:

0.05% @ -15dBu

Intermodulation Distortion:

0.2% @ -20dBu

Input Impedance:

220K Ohms input A, 220K/10M Ohms input B

Output Impedance:

300 Ohms at XLR

Equivalent Input Noise:

-92dBu at XLR

Noise Floor:

-100dB

Maximum Input:

+7 dBu

Features

180° polarity reverse, Ground lift, HPF, Boost

Input Connectors:

1/4"

Output Connectors:

1/4", XLR

General

Construction:

14 gauge steel

Size (L x W x D):

5.5" x 4.2" x 2" (203 x107 x 48mm)

Weight:

2.55lb (1157 grams)

Power:

+15VDC/400mA adapter included

Conditions:

For use in dry locations only between 5°C and 40°C

Warranty:

Radial 3-year, transferable
