Radial Engineering Bassbone OD Bass Preamp & Overdrive

Radial EngineeringSKU: R800 7072 00

Price:
Sale price €549.00

The Bassbone OD is a bass preamp that features two fully-equipped input channels, each with separate level and EQ controls and a shared overdrive.

Dual full-featured bass channels

The Bassbone OD allows you to connect two bass guitars and sculpt the tone of each one individually, as each input has its own level and EQ controls. The EQ settings have been specifically tailored for use with basses, and include a high pass filter to roll off excessive low end, along with a selectable center frequency for the Mid EQ boost/cut. Input A features a PZB booster designed for use with upright basses that employ a piezo transducer, while Input B includes a Drag Control impedance correction circuit that adjusts the load presented to magnetic pickups for a more natural tone. Following the input and EQ section, the Bassbone OD allows both instruments to share your effects pedals with an EFX Loop, which then feeds a powerful on-board overdrive.

Bassbone OD Applications

Bassbone OD Applications: 2 Basses

Bassbone OD with two basses

Toggle between your favourite vintage bass and your active 5 string using the middle footswitch and send the signal to your amp. Mute the signal using the right hand footswitch for quiet on-stage tuning using the tuner out.

Bassbone OD with electric and upright

Whether you play jazz, pop or orchestral works, the Bassbone OD lets you switch between a passive bass with magnetic pickups to an upright with piezo while optimising the tone for each. Add effects to the signal path using the built-in effects loop.

Bassbone OD Applications: 2 pickups

Combine two pickups and mix together

Connect the TRS (stereo out) from your dual-element bass to combine a magnetic pickup with a piezo using the blend switch. Set the levels and tone for each pickup to suit. The Bassbone OD acts like a mini 2 channel mixer!

Features:

  • Toggle between any two basses with ease
  • Individual EQ controls for each input
  • Headphone output for silent practice
  • PZB booster and piezo input for upright bass
  • Built-in Radial DI with balanced output for the PA

Specifications



Audio circuit type:

Discrete class-A FET input with low noise ICs.

Frequency response:

20Hz ~ 18kHz

Dynamic range:

85dB

Gain:

Unity gain device

Clip Level:

+10dBu at XLR

Total harmonic distortion:

0.05% @ -15dBu

Intermodulation Distortion:

0.2% @ -20dBu

Input Impedance:

CH-A: 220K/10M CH-B Variable from 22K to 1.8M

Output Impedance:

300 Ohms at XLR

Equivalent Input Noise:

-92dBu at XLR

Noise Floor:

-100dB

Maximum Input:

+7 dBu

Features

180° polarity reverse, Ground lift, HPF, Drag Control, Level Control, Phase Adjustment, Effects Loop, EQ Control, Boost

Input Connectors:

1/4"

Output Connectors:

1/4", XLR, 3.5mm

General

Construction:

14-gauge steel

Size (L x W x D):

8" x 4.2" x 2" (203 x107 x 48mm)

Weight:

2.55lb (1157 grams)

Shipping size (L x W x D):

10.75" x 5"x 2.75" (273 x 127 x 70mm)

Shipping weight:

2.8lb (1270 grams)

Power:

+15VDC/400mA adapter included

Conditions:

For use in dry locations only between 5°C and 40°C

Warranty:

Radial 3-year, transferable
