The ioStation 24c audio interface and production controller provides essential tools to record, mix, and produce in an ergonomic desktop design that fits into any home studio. Record through two pristine XMAX mic preamps and high-definition 24-bit, 192 kHz analog-to-digital converters. Navigate your recordings with easy-to-use transport controls. Edit your production and automate parameters with the powerful Session Navigator and mix using a 100 mm touch-sensitive motorised fader. Whether you’re producing your latest album or just getting started with your first podcast, the ioStation 24c lets you record and mix, with tactile controls—all on a single USB connection.
FEATURES:
- USB-C™ compatible (USB 2.0), 24-bit/192 kHz 2x2 audio interface and production controller
- 2 transparent XMAX Class A mic preamps to capture every detail
- 2 high-headroom instrument/line inputs to record guitar, bass, and your favourite synths
- High-powered headphone amp with Mix knob for zero-latency, analog monitoring
- 2 balanced ¼-inch Line outputs with dedicated level control
- Single touch-sensitive, 100 mm long-throw, motorised fader
- Transport controls with solo, mute, and record arm
- Innovative Session Navigator controls make mixing and controlling DAWs quick and easy
- Seamless, native support for Studio One
- Compatible with Logic Pro X, Cubase, Ableton Live, and Pro Tools via MCU and HUI
- USB-C to USB-C and USB-C to USB-A cables included
- Studio One® Artist and Studio Magic Plug-in Suite included
Computer system requirements:
Below are the minimum computer-system requirements for the ioStation 24c.
Mac
- macOS® 10.11 or higher (64-bit only)
- Intel® i-series 2 GHz multicore processor (or AMD equivalent) or faster
- 4 GB RAM (8 GB or more recommended)
Windows
- Windows® 7 x64 SP1 + platform update, Windows 8.1 x64, Windows 10 x64
- Intel i-series 2 GHz multicore processor (or AMD equivalent) or faster
- 4 GB RAM (8 GB or more recommended)
Mac and Windows Systems
- USB-C™ or USB-A 2.0 port compatibility
- 32 GB hard disk space
- PreSonus Universal Control 2.0 or higher
- Monitor with 1366x768 resolution (high-dpi monitor recommended)
- Multitouch-enabled monitor required for touch operation
Note: The minimum system requirements may differ for DAWs other than Studio One. Please check the requirements for your DAW of choice with its manufacturer.
Note that the speed of your processor, amount of RAM and size and speed of your hard drive will greatly affect the overall performance of your recording system. Also, a more powerful system (faster processor with more RAM) will allow for lower latency (signal delay) than you might experience while monitoring audio signals.
Technical Specifications
|
Microphone Preamp |
|
|
Type |
XLR Female (via Combo), Balanced |
|
Maximum Input Level |
+16 dBu (Balanced, min. gain) |
|
Gain Control Range |
80 dB |
|
Frequency Response |
20 Hz to 20 kHz (±0.15 dB, unity gain, 48 kHz) |
|
Dynamic Range |
> 107 dB (A-wtd, min. gain) |
|
Total Harmonic Distortion |
< 0.007% (1 kHz, min. gain) |
|
EIN |
< -128 dBu (max gain, 40Ω, 22 kHz BW, A-wtd) |
|
Input Impedance |
1.6 kΩ |
|
Phantom Power |
+48V, > 8 mA per input |
|
Instrument Inputs |
|
|
Type |
¼” TS Female (via Combo), Unbalanced |
|
Maximum Input Level |
+15 dBu (Unbalanced, min. gain) |
|
Gain Control Range |
80 dB |
|
Frequency Response |
20 Hz to 20 kHz (±0.2 dB, unity gain, 48 kHz) |
|
Dynamic Range |
> 110 dB (A-wtd, min. gain) |
|
Total Harmonic Distortion |
< 0.012% (1kHz, -1 dBFS, min. gain) |
|
Input Impedance |
> 1 MΩ |
|
Line Inputs |
|
|
Type |
¼” TRS Female (via Combo), Balanced |
|
Maximum Input Level |
+ 22 dBu (Balanced, min. gain) |
|
Frequency Response |
20 Hz to 20 kHz (±0.05 dB, unity gain, 48 kHz) |
|
Dynamic Range |
> 114 dB (A-wtd, min. gain) |
|
Total Harmonic Distortion |
< 0.007% (1 kHz, -1 dBFS, min. gain) |
|
Input Impedance |
10 kΩ |
|
Main and Line Outputs |
|
|
Type |
¼” TRS Female, impedance balanced |
|
Maximum Output Level |
+18 dBu (Balanced) |
|
Frequency Response |
20 Hz to 20 kHz (±0.2 dB, unity gain, 48 kHz) |
|
Dynamic Range |
> 109 dB (A-wtd) |
|
Total Harmonic Distortion |
< 0.005% (1 kHz, +4 dBu) |
|
Headphone Outputs |
|
|
Type |
¼” TRS Female, Stereo, Unbalanced |
|
Maximum Output Level |
150 mW/channel (56Ω load) |
|
Frequency Response |
20 Hz to 20 kHz (±0.2 dB, 56Ω load, 48 kHz) |
|
Dynamic Range |
> 107 dB (A-wtd) |
|
Total Harmonic Distortion |
< 0.02% (1 kHz, -1 dBFS, no load) |
|
Headphone Impedance (working range) |
32Ω to 300Ω |
|
Digital Audio |
|
|
Connection Type |
USB 2.0 over USB-C™ Compatible Connection |
|
ADC Dynamic Range |
115 dB (A-wtd) |
|
DAC Dynamic Range |
115 dB (A-wtd) |
|
Bit Depth |
24 bits |
|
Internally Supported Sample Rates |
44.1, 48, 88.2, 96, 176.4, 192 kHz |
|
Clock |
|
|
Jitter |
< 70 ps RMS (20 Hz – 20 kHz) |
|
Jitter Attenuation |
> 60 dB (1 ns in => 1 ps out) |
|
Power |
|
|
|
12 VDC, 1.2A, external power supply |
|
Physical |
|
|
Height |
2.4" (61 mm) |
|
Depth |
6.8" (172 mm) |
|
Width |
9.6" (244 mm) |
|
Weight |
2.2 lbs (1 kg) |
