The most portable AudioBox lets you record anything, anywhere; Mic, Line, and Instrument inputs; +48v phantom power for condenser microphones; mix control for hardware/software monitor blend; front-mounted Headphone jack; balanced stereo Main Outputs for professional studio monitors; includes Studio Magic and Studio One Prime.
Grab and Go! With AudioBox GO, you can record wherever sound takes you. Track some acoustic guitar down by the lake, or lay down some soaring vocals in that super-reverberant stairwell in your friend’s apartment building. Or collect some gritty samples for your next beat down at the subway terminal. AudioBox GO will get you out of the house and make recording the adventure that it should be.
AudioBox GO is a pocket-sized dynamo with all the connections you need to connect professional XLR vocal mics, guitars, synthesizers, headphones, and studio monitors, so it’s also fantastic for compact laptop-based studio setups where desk space is a hot commodity. It's USB class-compliant, so there are no special drivers or applications for you to download and install—and it’s bus-powered, which means no fussing about with power supplies.
Best of all, you’ll be making music from day one, because the AudioBox GO includes Studio One® Prime—the most intuitive digital audio workstation around—as well as Studio Magic, a bundle of over $1000 worth of plug-ins, software, and tutorials.
Features
- Ultra-compact, mobile 2x2 USB audio interface
- 1 XLR combo Microphone/Line input with +48v phantom power
- 1 TS Instrument input
- 1 TRS 1/4" stereo Headphone output
- 2 TRS 1/4" Main outputs
- Sample rate support up to 96khz
- Studio One Prime recording software and Studio Magic software bundle included
Computer system requirements:
Below are the minimum computer-system requirements for AudioBox GO. For Studio One system requirements, please click here.
macOS®
- macOS version 10.13 or later
- 200 MB storage space and 4 GB RAM for Universal Control (required for firmware updates)
- Available USB port
Windows®
- Windows 10 or later (64-Bit Only)
- 200 MB storage space and 4 GB RAM for Universal Control (required for firmware updates and low-latency ASIO support)
- Available USB port
Chrome OS
For information on compatibility with Chrome OS, click here.
iOS/iPadOS
For information on compatibility with iOS/iPadOS, click here.
Android
For information on compatibility with Android devices, click here.
The above are the hardware system requirements for this product.
DAW software and Operating System requirements vary.
Click here for Studio One’s system requirements.
Technical Specifications
|
Microphone Preamp |
|
|
Type |
XLR female, balanced (via Combo connector Input 1) |
|
Frequency Response (±3.0 dB) |
20 Hz to 20 kHz |
|
Input Impedance (Balanced) |
1.4kΩ |
|
THD+N (unwtd, 1 kHz @ +4 dBu Output, Unity Gain) |
< 0.004% |
|
Gain Control Range (± 1 dB) |
50 dB (0 dB to +50 dB) |
|
Max Input Level (Unity Gain, 1 kHz @ 0.5% THD+N) |
+10 dBu (± 0.5 dBu, min gain) |
|
Phantom Power (±2 VDC) |
+48 VDC (±2 VDC) |
|
Line Input |
|
|
Type |
¼" TRS female, balanced (via Combo connector Input 1) |
|
Input Impedance |
750 kΩ |
|
Max Input Level |
+19 dB |
|
Gain Control Range |
50 dB (-20 dB to +30 dB) |
|
Instrument Input |
|
|
Type |
¼" TS female, unbalanced (Input 2) |
|
Input Impedance |
750 kΩ |
|
Max Input Level |
+13 dB |
|
Gain Control Range |
50 dB (0 dB to +50 dB) |
|
Line Outputs |
|
|
Type |
¼" TRS female, impedance balanced |
|
Frequency Response |
20 Hz to 20 kHz, +/-0.2 dB |
|
Output Impedance |
51Ω |
|
THD+N (1 kHz, 20 kHz BW, A-wtd) |
<0.007% |
|
Headphone Output |
|
|
Type |
¼" TRS active stereo |
|
Maximum Output |
30 mW/ch. @ 60Ω Load |
|
Frequency Response (±1.0 dB) |
20 Hz - 20 kHz, +- 0.5 dB |
|
THD+N (1 kHz, max gain, 20 kHz BW, A-wtd) |
<0.08% |
|
S/N Ratio (1 kHz, max gain, 20 kHz BW, A-wtd) |
90 dB |
|
Power |
|
|
Type |
Bus Powered |
|
Digital Audio |
|
|
Connection Type |
USB 2.0 over USB-C® compatible connection |
|
ADC Dynamic Range (A-wtd, 48 kHz Sample Rate) |
90 dB |
|
DAC Dynamic Range (A-wtd, 48 kHz Sample Rate) |
102 dB |
|
Bit Depth |
24 |
|
Reference Level for 0 dBFS |
+10 dBu |
|
Supported Sample Rates (kHz) |
44.1, 48, 88.2, 96 |
|
Physical |
|
|
Height |
1.73” (44 mm) |
|
Depth |
3.3" (84 mm) |
|
Width |
4.25" (108 mm) |
|
Weight |
0.51 lb (0.24 kg) |
