One or two 5.8 GHz true diversity receiver modules with 10 auto-scannable frequencies. One-touch Scan & Sync (ACT) button for fast and easy channel setup.
50W Class-D amplifier to power a 5" full-range driver.
Built-in high-efficiency active antennas prevent accidental antenna breakage and ensure improved reception distance and stable signal quality.
The mixed output of wired mic, wireless mic and USB.
3.5 mm line input accepts external iPod, MP3/CD/DVD player or laptop.
Built-in Bluetooth to connect mobile devices for music streaming.
Built-in one-button fade-in alarm siren for warning.
ID code setting to prevent the interference from the same operating channel and increase compatible channels at the same venue.
External AC switching power supply for fast battery charge. Built-in high capacity lithium battery provides the amplifier complete operation without AC power.
4-hour full charge for 10-hour stand-by time.
A 4-level battery indicator for monitoring the battery level and charging state.
Model
MA-303SG / MA-303DG
Name
Portable Wireless PA Systems
Power Output
60 Watts (max.), Class D, T.H.D < 1%
Frequency Response
50 Hz ~ 18 kHz
Speaker
1 " Tweeter & 5 " , Woofer
Sensitivity
Typical: 92 dB, Maximum: 102 dB
Audio Inputs
Mic-in: Ø 6.3 mm (1/4 ") × 1
Line Inputs / Outputs
Ø 3.5 mm (1/8 ")
Extension Speaker
N/A
Storage
N/A
Power Supply
External 100 ~ 240 V AC switching power supply (Max. Power Consumption: 60 W)
Bluetooth connectivity and USB player and recorder
Microphones
MM-59, MM-590 (Optional)
Patents
Patented. Telecom & safety regulations approved.
Notes
Refer to Accessories for specifications of the receivers, transmitters, interlinking transmitters and audio players. Refer to the actual product in the event of product description discrepancy.
