Grace Design m303 Active DI Box

Grace DesignSKU: m303

Price:
Sale price €395.00

The all new Grace Design m303 is an active, truly-isolated direct box, delivering next-generation audio performance for all live stage and studio applications. Our advanced power supply design provides incredible headroom and dynamic range. A custom-wound Lundahl transformer outputs amazing low-end clarity and high frequency detail. All of this performance is packaged in a beautiful and rugged 1⁄4” extruded aluminum chassis. Don’t let the elegant exterior fool you, this thing is built.

Features

  • Phantom powered active DI with full galvanic isolation.
  • Custom wound Lundahl transformer, magnetically shielded with a high nickel core
  • Ultra-low distortion (below -100dB at 1kHz, below -80dB at 50Hz)
  • Ultra-low noise (-118dBu, A weighting)
  • Ultra-wide bandwidth 20-80kHz
  • Wide dynamic range (124dB)
  • Excellent low frequency headroom THD+N @50Hz <-80dB (0.007%)
  • 1M Ohm input impedance works with any line or pickup signal source
  • Peak indicator LED - 3dB before clipping
  • Power indicator LED
  • Efficient design only draws 4mA of phantom power current
  • Through signal connector
  • Fully ESD and RFI protected
  • Input pad (13dB) for high level signals
  • High-quality gold contact toggle switches
  • Very rugged 1/4" wall extruded aluminium chassis, recessed connectors

m303 advantages over many other DI products

  • Signature Grace Design transparent, musical audio performance
  • Active design with true galvanic isolation
  • World class Lundahl transformer
  • Incredibly low distortion and noise with wide dynamic range
  • Deep, rock-solid bass response
  • 1M ohm input impedance
  • Durable, designed for years of reliability
  • Backed by a 5 year warranty
  • Made in the USA

    Technical Specifications

    • Phantom powered active DI with full galvanic isolation.
    • Custom wound Lundahl transformer, magnetically shielded with a high nickel core
    • Ultra-low distortion (below -100dB at 1kHz, below -80dB at 50Hz)
    • Ultra-low noise (-118dBu, A weighting)
    • Ultra-wide bandwidth 20-80kHz
    • Wide dynamic range (124dB)
    • Excellent low frequency headroom THD+N @50Hz <-80dB (0.007%)
    • 1M Ohm input impedance works with any line or pickup signal source
    • Peak indicator LED - 3dB before clipping
    • Power indicator LED
    • Efficient design only draws 4mA of phantom power current
    • Through signal connector
    • Fully ESD and RFI protected
    • Input pad (13dB) for high level signals
    • High-quality gold contact toggle switches
    • Very rugged 1/4" wall extruded aluminium chassis, recessed connectors
