The ART USBMix4 is a great starting point for building a personal home studio. Perfect for podcasters, songwriters or at home movie makers looking for a simple solution for recording voiceovers, location recording or adding music to your projects using any Mac or PC.
Key Features
- High Performance Low Noise Design
- Switchable +48v Phantom Power (CH1)
- Assignable USB Record Source
- Independent Level Controls for Main and Headphone/Monitor Outputs
- 1/8th-inch Headset Connectors (Mono Mic In and Stereo Headset Out)
- Integrated Class Compliant Plug-and-Play USB Audio for Mac & PC
- Operates on USB Power or 5VDC External Power Supply (Included)
Specifications
|
Input Connections |
XLR & ¼-inch Balanced Combi-jack (CH 1 & CH2) ¼-inch TRS Balanced (CH3 & CH4) 1/8-inch TRS Aux/MP3, 1/8-inch Headset Mic |
|
Output Connections |
¼-inch TRS Balanced Main Mix Outputs ¼-inch TRS Stereo Output & Monitor Outputs 1/8th-inch Headset Output |
|
Signal to Noise Ratio |
>90dB Typical (Ref 0dBu) |
|
Maximum Input Level |
+8dBu (Mic), +16dBu (1/4-inch Input) |
|
Maximum Output Level |
+15dBu Main Mix Outputs |
|
Maximum Gain |
>55dB (Mic), >37dB (Instrument), 5dB (CH3 & CH4) |
|
USB Computer Interface |
USB Class Compliant plug-and-play Mac / PC Interface |
|
Power |
Via USB or 5VDC @ 500mA |
|
Dimensions |
1.75″H x 5.1″W x 7.5″D (45mm x 130mm x 191mm) |
