The ASF-2 MKII Hydrophone is affordable, easy to use – and simply a great sounding hydrophone. Designed with key components used in the renowned ASF-1 MKII, the ASF-2 MKII effectively utilises the same professional hydrophone technology for outstanding underwater audio capture.
With a frequency range of 70Hz-20kHz, we designed a microphone able to capture a perfect spectrum of sounds while effectively avoiding low frequency noise created by cable handling.
Designed to withstand roughest conditions
The housing is machined out of high-quality aluminium with an anodised exterior for protection against the corrosive nature of seawater, while the 10m polyurethane cable is cast into the housing for a water-tight seal. These design attributes enable the ASF-2 MKII Hydrophone to easily withstand the roughest field conditions. In addition to being an affordable hydrophone, the ground-breaking design of the ASF-2 is makes it affordable to operate as it is compatible with standard professional audio equipment.
Terminated with an XLR connector and powered by 48V Phantom, this plug-and-play hydrophone is designed for use with today’s professional field mixers and recorders for outstanding underwater recordings.
Never before has professional underwater audio capture been so affordable.
Technical Details
- Linear Frequency Range 70Hz - 20kHz
- Polar Pattern: Omnidirectional
- Max THD 0,1% (70Hz - 20kHz)
- Power Consumption 5mA
- (L / W / H) 47 x 30 x 30 mm (without cable)
- Max depth: 30m
- Material: Anodised seawater resistant aluminium
- Capsule Material Special formulated NBR
- Weight (without cable): 50g (without cable)
- Power Supply: 48V Phantom
