ENHANCE YOUR RIBBONS
The AEA RPQ500 Ribbon Preamp and EQ provides one channel of high-output, high-impedance, and low-noise gain with a rich and natural sound that brings out the full potential of your microphones.
Specifically designed for ribbon microphones, the RPQ500 excels at drawing out the warmth and lush sound that ribbons are uniquely known for.
POWERHOUSE IN A 500 FORMAT
The RPQ500 is a powerhouse that provides unparalleled high gain with low-noise. With 81db of JFET output, the RPQ500 gives you enough juice to record soft sources without ever having to worry about noise.
IT'S OH SO QUIET
With the RPQ500, you will never consider a source too quiet to record with a ribbon mic ever again. Passive ribbons with low output levels require preamps that supply a high level of output. If the preamp you use doesn’t have enough clean gain, the mic signal may seem too soft or noisy which may be apparent when recording quiet acoustic guitars or strings, especially at a distance or with long cable runs. The RPQ500 eliminates this concern.
CURVESHAPER EQ
The RPQ500’s CurveShaper™ EQ is a powerful tool that gives you the ability to control your ribbons right at the start of the signal path. Adjustable low and high-frequency controls allow you to tame proximity problems and provide high-frequency extension with slope control.
The high-frequency filter boost enables you to add presence and air to your source –perfect for sources like ribbons and 2-busses that often benefit from some extra top-end. The low-frequency control easily removes bass build-up in a fast and unobtrusive way.
HIGH IMPEDANCE MAKES A HUGE DIFFERENCE
The sound and tonality of dynamic microphones like ribbons and moving-coils are directly affected by the impedance of a preamp. The higher the impedance, the better the sound. The RPQ500 boasts an extra high input impedance of 10K Ohms.
Preamps with an impedance of under 10k ohms will limit the lows, highs, and transients of your passive microphones. The RPQ500’s high impedance will reveal your microphone’s true nature– a thick low-end, open top-end, and articulate transient response that you will need to hear to believe.
Both condensers and active microphones will also benefit from the RPQ500’s impedance.
The RPQ500 is a workhorse tool for your 500 rack. Many mixing and mastering engineers turn to the RPQ500 purely for its EQ functionality.
The Line/Mic switch bypasses the microphone gain stage and allows the EQ to be used for tracking with other preamps or during mixdown.
Add the output level control, and the RPQ500 becomes a high-quality processing tool that can be used for mixing and mastering when combined with summing racks and mixers such as the Purple Audio Moiyn or the Roll Music Folcrom.
EXCEPTIONAL PREAMPS
Passive microphones, coupled with AEA’s range of ribbon-specific preamps, are the key choice for discerning recordists who want total control over their signal path.
AEA offers the RPQ2, RPQ500 and TRP2 microphone preamps, all of which provide unmatched clean levels of gain, and a high impedance. All AEA Ribbon Preamps all share the same topology and sound. The differences between each unit come down to extra features and form factor.
- Gain at 1kHz: 81dB of gain at 1kHz, balanced-in to balanced-out in Microphone Input Mode
- Noise figure, rms A-weighted: < 2dB
- Noise figure, rms unweighted: < 3dB, 20 kHz LPF bandwidth
- EIN: < -130 dBu A-weighted, 150 Ohm resistive source
- Frequency response: -3dB < 1Hz and > 100 kHz
- THD: < 0.02% at 1 kHz
- Input impedance: 10K Ohms
- Balanced Line Input Impedance: 20K Ohms
- Color LEDs: Green, Yellow, Red
- XLR output maximum level into 600Ω load: +28 dBu, balanced; 0 dBu = 0.7746 V rms
- XLR connectors polarity: Pin-1 is ground, pin-2 is high, pin-3 is low
- Size: 1.5” w, 6.8” d, 4.5” h (3.8cm x 17.27cm x 11.43cm)
- Weight: 11.7oz (~0.33 kg)
